CGOLDENWALL RW-ST01A Load Cell Sensor Amplifier Transmitter with Dual Signal Output (0-10V & 4-20mA / 0-5V & 4-20mA) - Strain Gauge Amplifier for Industrial Weighing Systems, Process Control & Laboratory Equipment

$87.45

$159

Safe 45%

CGOLDENWALL RW-ST01A Load Cell Sensor Amplifier Transmitter with Dual Signal Output (0-10V & 4-20mA / 0-5V & 4-20mA) - Strain Gauge Amplifier for Industrial Weighing Systems, Process Control & Laboratory Equipment

$87.45

$159

45% Off

Delivery & Return: Free shipping on all orders over $50

Estimated Delivery: 10-15 days international

7 people viewing this product right now!

SKU: 21866867

Guranteed safe checkout

Description

Product Description: Enclosure:ABS Net Weight:90g Applicable Sensitivity:1.0 or 2.0 mV/V±10% Input Signal:mV Output Signal:0-5V/10V&4-20mA Accuracy:0.3% Power Supply:DC24V Applicable Load Cell Excitation Voltage:5-12V Load Capacity:Parallel Connection of 350Ω Load cell 4 pcs at most Temperature Coefficient:Better than 100ppm Operating Temperature Range:0-50ºC Enclosure:IP65 Installation Mode:Enclosure Fixed Mounting

Shipping & Returns

For all orders exceeding a value of 100USD shipping is offered for free.

Returns will be accepted for up to 10 days of Customer’s receipt or tracking number on unworn items. You, as a Customer, are obliged to inform us via email before you return the item.

Otherwise, standard shipping charges apply. Check out our delivery Terms & Conditions for more details.

Features

Description EnclosureABS
Net Weight90g

SpecificationApplicable Sensitivity1.0 or 2.0 mV/V±10%
Input SignalmV
Output Signal0-5V/10V&4-20mA
Accuracy0.3%
Power SupplyDC24V
Applicable Load Cell Excitation Voltage5-12V
Load CapacityParallel Connection of 350Ω Load cell 4 pcs at most
Temperature CoefficientBetter than 100ppm

Working EnvironmentOperating Temperature Range0-50ºC
EnclosureIP65
Installation ModeEnclosure Fixed Mounting

FeatureWaterproof design and good sealing 24 bit ADC resolution Digital filter inside Direct output ADC result RS232 or RS485 interface Simple communication command Excellent temperature stability Application All full bridge stain gauge load cells for weighing, tension, compression, torque, etc.
